Bore Fitting Size Length Minimum Length Working Pressure (BAR) Safety Factor (MIN) Bend Radius (MM)
- (DN10 (3/8”)) 3/8” – ½” - 150mm 20 4:1 40
- (DN12 (1/2”)) ½” – ¾” - 150mm 20 4:1 60
- (DN16 (5/8”)) ½” – ¾” - 150mm 16 4:1 70
- (DN20 (3/4”)) ½” – ¾” - 180mm 16 4:1 80
- (DN25 (1”)) 1” - 180mm 10 4:1 100
- (DN32 (1 ¼”)) 1 ¼” - 230mm 10 4:1 160
- (DN40 (1 ½”)) 1 ½” - 250mm 6 4:1 180
- (DN50 (2”)) 2” - 250mm 6 4:1 230
Temperature Range
-20C to +110°C
Standards

ISO9001-2008

BSRIA BG4/2004 (up to 1”)

WRAS Approved Version Available (up to 1”)
