Cylinders, Pneumatic Cylinder & Mountings, Pneumatics
Compare
1/8″ BSPP Compact Cylinder
From: £284.69
Compact Cylinder Aevu-80-25-P-A For Proximity Sensing, Piston-Rod End With Female Thread. Stroke=25 Mm, Piston Diameter=80 Mm, Cushioning=P: Flexible Cushioning Rings/Plates At both Ends, Assembly Position=Any, Mode Of Operat...Read more
Click and collect from one of our 28 branches
Compare
Total : £0.00
| Part Number | Barrel Material | Bore Size mm | Piston Rod Material | Piston Rod Thread Gender | Stroke Length mm | Working Pressure bar | Working Temperature | List Price | 1-9 Price | 10+ Price | Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 156971 | Wrought Aluminium Alloy | 80 | Stainless Steel | Female | 25 | 0.6 to 10 | -20°C to +80°C | £751.17 | £687.24 | ||
| 156970 | Wrought Aluminium Alloy | 80 | Stainless Steel | Female | 20 | 0.6 to 10 | -20°C to +80°C | £738.27 | £675.44 | ||
| 156969 | Wrought Aluminium Alloy | 80 | Stainless Steel | Female | 15 | 0.6 to 10 | -20°C to +80°C | £725.30 | £663.57 | ||
| 156968 | Wrought Aluminium Alloy | 80 | Stainless Steel | Female | 10 | 0.6 to 10 | -20°C to +80°C | £712.26 | £651.64 | ||
| 156967 | Wrought Aluminium Alloy | 63 | Stainless Steel | Female | 25 | 0.6 to 10 | -20°C to +80°C | £588.96 | £538.83 | ||
| 156966 | Wrought Aluminium Alloy | 63 | Stainless Steel | Female | 20 | 0.6 to 10 | -20°C to +80°C | £577.05 | £527.94 | ||
| 156965 | Wrought Aluminium Alloy | 63 | Stainless Steel | Female | 15 | 0.6 to 10 | -20°C to +80°C | £565.20 | £517.10 | ||
| 156963 | Wrought Aluminium Alloy | 50 | Stainless Steel | Female | 25 | 0.8 to 10 | -20°C to +80°C | £478.61 | £437.88 | ||
| 156962 | Wrought Aluminium Alloy | 50 | Stainless Steel | Female | 20 | 0.8 to 10 | -20°C to +80°C | £467.90 | £428.07 | ||
| 156961 | Wrought Aluminium Alloy | 50 | Stainless Steel | Female | 15 | 0.8 to 10 | -20°C to +80°C | £457.20 | £418.29 | ||
| 156960 | Wrought Aluminium Alloy | 50 | Stainless Steel | Female | 10 | 0.8 to 10 | -20°C to +80°C | £446.59 | £408.58 | ||
| 156959 | Wrought Aluminium Alloy | 40 | Stainless Steel | Female | 25 | 0.8 to 10 | -20°C to +80°C | £413.62 | £378.42 | ||
| 156958 | Wrought Aluminium Alloy | 40 | Stainless Steel | Female | 20 | 0.8 to 10 | -20°C to +80°C | £404.27 | £369.86 | ||
| 156957 | Wrought Aluminium Alloy | 40 | Stainless Steel | Female | 15 | 0.8 to 10 | -20°C to +80°C | £394.97 | £361.36 | ||
| 156956 | Wrought Aluminium Alloy | 40 | Stainless Steel | Female | 10 | 0.8 to 10 | -20°C to +80°C | £385.58 | £352.76 | ||
| 156955 | Wrought Aluminium Alloy | 40 | Stainless Steel | Female | 5 | 0.8 to 10 | -20°C to +80°C | £376.28 | £344.26 | ||
| 156954 | Wrought Aluminium Alloy | 32 | Stainless Steel | Female | 25 | 0.8 to 10 | -20°C to +80°C | £317.97 | £290.91 | ||
| 156953 | Wrought Aluminium Alloy | 32 | Stainless Steel | Female | 20 | 0.8 to 10 | -20°C to +80°C | £309.60 | £283.25 | ||
| 156952 | Wrought Aluminium Alloy | 32 | Stainless Steel | Female | 15 | 0.8 to 10 | -20°C to +80°C | £301.33 | £275.69 | ||
| 156951 | Wrought Aluminium Alloy | 32 | Stainless Steel | Female | 10 | 0.8 to 10 | -20°C to +80°C | £293.07 | £268.12 | ||
| 156950 | Wrought Aluminium Alloy | 32 | Stainless Steel | Female | 5 | 0.8 to 10 | -20°C to +80°C | £284.69 | £260.46 |
Total : £0.00
Compact Cylinder Aevu-80-25-P-A For Proximity Sensing, Piston-Rod End With Female Thread. Stroke=25 Mm, Piston Diameter=80 Mm, Cushioning=P: Flexible Cushioning Rings/Plates At both Ends, Assembly Position=Any, Mode Of Operation=(* Single-Acting, * Pushing Action), Festo
