Nautilus Fuelmaster A1 Marine Fuel Delivery Hose
From: £118.75
Compare
| Part Number | ID mm | ID Inch | OD mm | Bend Radius | Working Pressure Bar | Burst Pressure Bar | Coil Length | List Price | 1-9 Price | 10+ Price | Quantity |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MFHA1-5-10 | 5mm | 3/16" | 12.5mm | 50mm | 10 | 30 | 10m | £118.75 | £101.79 | ||
| MFHA1-5-100 | 5mm | 3/16" | 12.5mm | 50mm | 10 | 30 | 100m | £1,187.50 | £1,017.86 | ||
| MFHA1-6-10 | 6mm | 1/4" | 13.5mm | 60mm | 10 | 30 | 10m | £134.58 | £115.36 | ||
| MFHA1-6-100 | 6mm | 1/4" | 13.5mm | 60mm | 10 | 30 | 100m | £1,345.83 | £1,153.57 | ||
| MFHA1-8-10 | 8mm | 5/16" | 16.5mm | 80mm | 10 | 30 | 10m | £147.50 | £126.43 | ||
| MFHA1-8-100 | 8mm | 5/16" | 16.5mm | 80mm | 10 | 30 | 100m | £1,475.00 | £1,264.29 | ||
| MFHA1-10-10 | 10mm | 3/8" | 18.5mm | 100mm | 10 | 30 | 10m | £169.58 | £145.36 | ||
| MFHA1-10-100 | 10mm | 3/8" | 18.5mm | 100mm | 10 | 30 | 100m | £1,695.83 | £1,453.57 | ||
| MFHA1-13-10 | 13mm | 1/2" | 22.5mm | 130mm | 10 | 30 | 10m | £232.50 | £199.29 | ||
| MFHA1-13-100 | 13mm | 1/2" | 22.5mm | 130mm | 10 | 30 | 100m | £2,325.00 | £1,992.86 | ||
| MFHA1-16-10 | 16mm | 5/8" | 25.5mm | 160mm | 10 | 30 | 10m | £259.58 | £222.50 | ||
| MFHA1-16-50 | 16mm | 5/8" | 25.5mm | 160mm | 10 | 30 | 50m | £1,297.92 | £1,112.50 | ||
| MFHA1-19-10 | 19mm | 3/4" | 29.5mm | 190mm | 10 | 30 | 10m | £325.83 | £279.29 | ||
| MFHA1-19-50 | 19mm | 3/4" | 29.5mm | 190mm | 10 | 30 | 50m | £1,629.17 | £1,396.43 |
Long length, smooth cover fire resistant fuel delivery hose.
Fully complying with EN standard ISO7840 A1, which is the recognized standard for fire resistant hoses for conveying fuel( petrol/ diesel) in permanently installed fuel systems for small craft up to 24m hull length.
Suitable for fuel supply and feed up to 10bar.
Manufactured from fuel resistant Nitrile( NBR) which is fire resistant.
Cover is fire resistant NBR which also gives excellent resistance to hydrocarbons, UV, ozone and abrasion.
Tube: Black, petrol & diesel oil, resistant NBR rubber
Reinforcement: Synthetic textile
Cover: Black, abrasion, ozone, weather, heat & oil resistant neoprene rubber, resistant to flame, abrasion, oil & sea conditions
Temperature: -35°c to + 100°c
| ID |
|---|
